Fanatec

Fanatec ClubSport Pedals V3 3.0 kg

$440.02 $449.00
Shipping calculated at checkout.

The Fanatec ClubSport Pedals V3 are a premium and highly adjustable pedal set designed for serious sim racers who demand precision, realism, and durability. Crafted with cutting-edge technology and robust materials, these pedals aim to provide a competitive edge and an immersive driving experience.

Product Features

  • High resolution pedals with magnetic and contactless sensors on gas and clutch for a long life and maximum performance
  • Pressure sensitive brake with custom made 90 kg load cell sensor
  • Adjustable brake stiffness and travel without tools
  • 12bit resolution (4096 values) on all axis
  • Alternative D-shape race plates in curved design. Ideal for standing pedals
  • Pedal extension to adjust the angle of the pedal plate and to change the angle of the whole pedal arm
  • Brake sensitivity can be adjusted through the tuning menu of the wheel and during the race
  • Vibration motor on throttle pedal indicates rear wheel spin and oversteer (control by games is possible via Fanatec Wheel SDK)
  • Vibration motor on brake pedal to simulate ABS and indicate locking tires (controlled by Fanatec wheels: Compatible to all games. Dynamic control by games is possible via Fanatec Wheel SDK)
  • Design of the gas pedal allows quick exchange of the springs. Two springs with different strength are included
  • Optional damper kit for gas and brake. The hydraulic dampening resistance can easily be adjusted with a knob
  • Full multi platform compatibility, depending solely on the platform compatibilities of the connected Wheel Base/Racing Wheel
  • Full metal construction of CNC-machined aluminum
  • Ultimate adjustability: Position of pedal plates in all directions, angle, spring strength at throttle, brake sensitivity, brake travel
  • Compatible to the colour kits to allow perfect visual customisation.

Compatibility
  • Playstation
  • PC
  • XBox

What's In The Box
  • ClubSport Pedals V3
  • 3x Pedal Extensions
  • 3x D-shape pedal plates
  • 1x Strong spring throttle (black)
  • 1x Strong spring clutch (black)
  • 1x RJ12 connection cable (150cm)
  • 1x USB connection cable (180cm)
  • 1x Lithium grease bottle
  • 1x Quick Guide

Warranty

3 Years by Endless Passion

Delivery and Shipping
  • Non-Campaign Periods: Delivery within 1-3 business days.
  • Campaign Periods: Delivery within 3-5 business days.
  • Out of Stock: If any items are out of stock, we will contact you through WhatsApp so please remain contactable!

For any questions, please contact us through WhatsApp!

Specifications

Platform Compatibility:
PC: Full compatibility via USB (no Fanatec wheel base required).
Xbox: Compatible when connected to a compatible Fanatec Xbox-licensed wheel base.
PlayStation: Compatible when connected to a compatible Fanatec PlayStation-licensed wheel base.
Note: Not directly compatible with consoles via USB.

Pedal Material:
Construction: Full metal construction, primarily CNC machined aluminum and steel.
Pedal Plates: D-shape pedal plates made from aluminum.

Sensors:
Brake Pedal:
Load Cell: 90 kg load cell sensor (max force measured).
Resolution: 12-bit (4096 values) when connected to a Fanatec wheel base.

Resolution (PC direct): Up to 16-bit (65536 values) depending on software/driver configuration.

Throttle Pedal:
Type: Contactless magnetic (Hall) sensor.
Resolution: 12-bit (4096 values) when connected to a Fanatec wheel base.
Resolution (PC direct): Up to 16-bit (65536 values) depending on software/driver configuration.

Clutch Pedal:
Type: Contactless magnetic (Hall) sensor.
Resolution: 12-bit (4096 values) when connected to a Fanatec wheel base.
Resolution (PC direct): Up to 16-bit (65536 values) depending on software/driver configuration.

Vibration Motors:
Quantity: Two vibration motors (one on throttle, one on brake pedal).
Connectivity:
USB Port: USB Type-B (for direct PC connection).
RJ12 Port: For connection to a Fanatec wheel base.

Mounting Options:
Standard Mounting Points: Multiple hard-mounting points on the bottom for secure attachment to sim racing cockpits or pedal plates.

Hole Pattern: Fanatec provides exact drilling templates for mounting.
Dimensions (approximate, unpacked):
Width: ~42.5 cm (16.7 inches)
Depth: ~31.5 cm (12.4 inches)
Height: ~26 cm (10.2 inches) (can vary slightly based on pedal plate position)
Weight (approximate, unpacked):
~5.0 kg (11.0 lbs)

Included Accessories:
USB cable
RJ12 cable
Various elastomers and springs for brake tuning.
Mounting hardware.
